WBX Series Stainless Steel Multi-stage Centrifugal Pump

Introduction
WBX Series Stainless Steel Multi-stage Centrifugal Pump

WBX series stainless steel multi-stage centrifugal pump (afterwards called pump)boasts characters of high efficiency, low noise, steady operation, etc. The pump set adopts the non-self-priming vertical multi-stage structure, which makes a compact whole ,its installation easy, its operation and maintenance convenient.

◎Application condition :
Medium temperature: normal type:0℃ ~68℃ hot water type:0℃ ~120℃，
Ambient temperature:+40℃ ,
Max ambient pressure:1.0MPa,
Advisable to use Motor & Generator of higher power in case that the density or viscosity of medium is above that of water.
PH: 5 to 8

◎Application fields:

Water supply	WXB	WXB(T)
Filtration and transfer at waterworks	●	●
Distribution from waterworks	●	●
Pressure boosting in mains	●	●
Pressure boosting in high-rise buildings, hotels, etc.	●	●
Pressure boosting for industrial water supply	●	●
Industry
Pressure boosting
Process water systems	●	●
Washing and cleaning systems	●	●
Vehicle washing tunnels	●	●
Fire fighting systems	●	●
Liquid transfer
Cooling and air-conditioning systems(refrigerants)	●	●
Boiler feed and condensate systems	●	●
Machine tools(cooling lubricants)	●	●
Aquafarming	●	●
Transfer
Oil and alcohol	●	●
Glycol and coolants	●	●
Water treatment
Ultra-filtration systems	●	○
Reverse osmosis systems	●	○
Softening, ionising, demineralizing systems	●	○
Distillation sys teams	●	○
Separators	●	○
Swimming baths	●	●
lrrigation
Field irrigation(flooding)	●	●
Sprinkler irrigation	●	●
Drip-feed irrigation	●	●

◎Certificate:

◎Electric Motor & Generator:
Full-enclosed and ventilating two-pole standard Motor & Generator
Protection class: IP55
Insulation class: F
Standard voltage Single phase 220V-50Hz Three phase:380/400V-50Hz
